1.8 Ton, Kubota Diesel Engine Mini Excavator | SE17SR

The AGT 1.8 Ton Mini Excavator is engineered for exceptional performance in tight spaces, delivering power and versatility for your toughest jobs. Powered by a Kubota 3-cylinder Tier 4 diesel engine, this compact powerhouse offers efficient fuel consumption and low emissions, making it a reliable choice for environmentally conscious projects.
Technical Data:

Operation Weight: 1.8 Ton
Engine: Tier 4 Diesel Engine
Horse Power: 13.5
Max Angle: 30 Degree

Features:

Kubota Compact 3-Cylinder Tier 4 Diesel Engine: Provides smooth, reliable power with superior fuel efficiency and reduced emissions.
Swing Boom: Offers enhanced maneuverability, allowing the operator to work in confined spaces and access hard-to-reach areas.
Quick Attach: Swiftly change attachments to increase jobsite productivity without the hassle.
2-Speed Travel: Switch between high and low speed settings for faster travel over long distances or better control in rough terrain.
Expandable Tracks: Easily adjust the track width to suit the job at hand, offering superior stability and balance on uneven ground.
Foldable Front Blade: Provides additional digging and grading capability while being compact for storage and transport.
Engine Monitoring System: Stay informed with real-time diagnostics and alerts, ensuring optimal performance and reducing downtime.

Specific Data:
Engine:

Brand: Kubota
Model: D902
Type: 3-cylinder, Tier 4 Diesel Engine
Power Output: 16 HP (11.8 kW) at 2,300 RPM
Emissions Compliance: EPA Tier 4F / Euro V

Performance:

Operating Weight: 1,800 kg
Maximum Digging Depth: 2,270 mm
Maximum Digging Height: 3,535 mm
Maximum Dumping Height: 2,445 mm
Maximum Digging Radius: 3,910 mm
Maximum Vertical Digging Depth: 1,910 mm
Maximum Digging Distance at Ground Level: 3,845 mm
Minimum Turning Radius (Working Device): 1,495 mm
Maximum Lifting Height of Bulldozer Blade: 280 mm
Maximum Digging Depth of Bulldozer Blade: 190 mm

Dimensions:

Overall Length: 3,575 mm
Overall Width: 990 mm (retractable to 1,300 mm)
Overall Height (to top of cab): 2,405 mm
Overall Height (to top of boom): 1,105 mm
Ground Length (During Transport): 2,440 mm
Ground Clearance of Counterweight: 460 mm
Minimum Ground Clearance: 145 mm
Tail Turning Radius: 650 mm
Track Length: 1,593 mm
Track Gauge: 760 mm (adjustable to 1,070 mm)
Standard Track Shoe Width: 230 mm
Turntable Width: 990 mm

Undercarriage:

Track Type: Rubber Tracks
Track Width: 990 mm (adjustable to 1,300 mm)

Additional Features:

Swing Boom: Equipped
Operator Cabin: Enclosed with ROPS (Roll-Over Protective Structure)
Hydraulic System: Auxiliary hydraulics for attachments
Controls: Pilot joystick controls
Blade: Dozer blade with adjustable height
